CGB2-100-1-SA
Crouse-Hinds CGB 1″ Aluminum Cable Gland, 0.875-1.375″, CGB2-100-1-SA
Lightweight Copper-Free Aluminum cable gland with 1″ NPT threads. Fits cables 0.875″ to 1.375″ (22.22 to 34.92 mm). Rated NEMA 3R, 4X.
Provides a heavy-duty mechanical seal and secure strain relief for non-armored and tray cables in demanding commercial and industrial electrical environments.
Brand: Crouse Hinds
Add to Quote Download Spec Sheet PDFFeatures
- Corrosion-resistant copper-free aluminum body and gland nut.
- Precision weatherproof seal with high-grade neoprene compression bushing.
- Lightweight construction with excellent mechanical strength.
- cULus Listed for Class I, Division 2 hazardous locations.
- Compatible with 1″ NPT threaded entries or clearance holes.
- Includes 3 interchangeable bushings for exceptional range versatility.
Specifications
| Catalog Number | CGB2-100-1-SA |
|---|---|
| Brand | Eaton Crouse-Hinds |
| Product Category | Cable Glands |
| Form Size | Standard |
| Number of Bushings | 3 |
| Gland Dimensions | Length Less Entry (F): 1.480″, Entry Thread Length (B): 0.700″, Hex Flats (G): 2.340″ |
Product Attributes
| Material | Copper-Free Aluminum |
|---|---|
| Thread Standard | NPT |
| Thread Size | 1″ |
| Cable Range (in) | 0.875 – 1.375″ |
| Cable Range (mm) | 22.22 – 34.92 mm |
| IP Rating | IP66 |
| NEMA Rating | NEMA 3R, 4X |
| Operating Temperature | -40°C to +100°C |
