CGB4913
Crouse-Hinds CGB 1-1/4″ Steel Cable Gland, 1.375-1.625″, CGB4913
Heavy-duty Feraloy® Iron Alloy non-armored cable gland with 1-1/4″ NPT threads. Fits cables 1.375″ to 1.625″ (34.92 to 41.27 mm). Rated NEMA 3R, 4.
Provides a heavy-duty mechanical seal and secure strain relief for non-armored and tray cables in demanding commercial and industrial electrical environments.
Brand: Crouse Hinds
Add to Quote Download Spec Sheet PDFFeatures
- Precision weatherproof seal with high-grade neoprene compression bushing.
- Robust Feraloy® Iron Alloy construction protects cables from damage and wear.
- NPT thread size 1-1/4″ provides secure connection to electrical boxes.
- cULus Listed for Class I, Division 2 hazardous industrial environments.
- Accommodates cable ranges from 1.375″ to 1.625″ (34.92-41.27 mm).
Specifications
| Catalog Number | CGB4913 |
|---|---|
| Brand | Eaton Crouse-Hinds |
| Product Category | Cable Glands |
| Form Size | E |
| Number of Bushings | 1 |
| Gland Dimensions | Length Less Entry (F): 2.625″, Entry Thread Length (B): 0.688″, Hex Flats (G): 3.000″ |
Product Attributes
| Material | Feraloy® Iron Alloy |
|---|---|
| Thread Standard | NPT |
| Thread Size | 1-1/4″ |
| Cable Range (in) | 1.375 – 1.625″ |
| Cable Range (mm) | 34.92 – 41.27 mm |
| IP Rating | IP66 |
| NEMA Rating | NEMA 3R, 4 |
| Operating Temperature | -40°C to +100°C |
